PT3342A
RoHS
RoHS compliant
RoHS compliantPackage 19-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTR 5.0V 6A 18-60 VIN HORZ
PDF
/
Inventory: 4290
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 32.3mm
Length 77mm
Height 12.7mm
Technical
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Max Output Current 6A
Output Voltage 5V
Voltage - Input (Max) 60V
Voltage - Isolation 1.5kV
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 19
Base Part Number PT3342
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 30W
Power Rating 30W
Subcategory Other Analog ICs
Additional Feature UNDERVOLTAGE LOCKOUT
Power (Watts) 30W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 19
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT3340 (30W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 19-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
