PT3105A
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 12V 1.25A 15W 6-Pin DIP Module
PDF
/
Buying Options
Total Price: USD $58.97
Unit Price: USD $58.973216
≥1 USD $58.973216
≥10 USD $55.63511
≥100 USD $52.485949
≥500 USD $49.515048
≥1000 USD $46.712311
Inventory: 1535
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 8.382mm
Technical
Isolation Isolated
Output Power 15W
Output Current 1.25A
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 12V
Max Output Current 1.25A
Output Voltage 12V
Voltage - Input (Max) 40V
Voltage - Isolation 500V
Efficiency 80%
Number of Outputs 1
Pin Count 6
Base Part Number PT3105
Depth 37.59mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Power Rating 15W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 1.67Lx1.48W x 0.33 H 42.4mmx37.6mmx8.4mm
Series PT3100 (15W)
Packaging Tray
Operating Temperature -20°C~70°C
Physical
Number of Pins 6
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
