PT3101A
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER DC-DC 15W 48V/5V
PDF
/
Buying Options
Total Price: USD $52.45
Unit Price: USD $52.451255
≥1 USD $52.451255
≥10 USD $49.482318
≥100 USD $46.681432
≥500 USD $44.039085
≥1000 USD $41.546307
Inventory: 1551
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 42.4mm
Length 37.6mm
Height 8.38mm
Technical
Isolation Isolated
Output Power 15W
Output Current 3A
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 5V
Max Output Current 3A
Output Voltage 5V
Voltage - Input (Max) 75V
Voltage - Isolation 500V
Efficiency 79%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XDMA-T5
Pin Count 6
Base Part Number PT3101
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Depth 37.3mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Power Rating 15W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT3100 (15W)
Packaging Tray
Operating Temperature -20°C~70°C
Physical
Number of Pins 6
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
