LMZ21701SILT
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 0.9-6V 6W
PDF
/
Buying Options
Total Price: USD $4.95
Unit Price: USD $4.9456
≥1 USD $4.9456
≥10 USD $4.44224
≥100 USD $4.199712
≥500 USD $3.63968
Inventory: 7679
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD Module
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series SIMPLE SWITCHER? Nano
Size / Dimension 0.14Lx0.14W x 0.07 H 3.5mmx3.5mmx1.8mm
Feature OCP, OTP, SCP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Terminal Position DUAL
Terminal Form BUTT
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LMZ21701
Number of Outputs 1
Efficiency 95%
Output Voltage 6V
Output Type Adjustable
Max Output Current 1A
Voltage - Output 1 0.9V~6V
Operating Supply Voltage 17V
Input Voltage-Nom 12V
Max Supply Voltage 17V
Min Supply Voltage 3V
Nominal Supply Current 17μA
Output Current 1A
Control Features Enable, Active High
Max Output Voltage 6V
Control Mode CURRENT/VOLTAGE-MODE
Control Technique PULSE WIDTH MODULATION
Min Output Voltage 900mV
Switcher Configuration BUCK
Max Duty Cycle 100 %
Max Junction Temperature (Tj) 125°C
Switching Frequency 2MHz
Dimensions
Height 1.75mm
Length 3.5mm
Width 3.5mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
