LMZ10501SILT
RoHS
RoHS compliant
RoHS compliantPackage 8-LDFN Exposed Pad, Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 0.6-3.6V 1A
PDF
/
Buying Options
Total Price: USD $3.08
Unit Price: USD $3.08
≥1 USD $3.08
≥10 USD $3.036
≥100 USD $2.992
≥500 USD $2.903648
≥1000 USD $2.815648
≥3000 USD $2.727736
Inventory: 5447
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 2.6mm
Technical
Switching Frequency 2.25MHz
Min Input Voltage (DC) 2.7V
Max Input Voltage (DC) 5.5V
Nominal Output Voltage 3.6V
Isolation Non-Isolated
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Control Mode CURRENT-MODE
Control Features Enable, Active High
Output Current 1A
Input Voltage-Nom 3.6V
Voltage - Output 1 0.6V~3.6V
Max Output Current 1A
Output Type Adjustable
Output Voltage 3.6V
Efficiency 95%
Number of Outputs 1
Pin Count 8
Base Part Number LMZ10501
Depth 3mm
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Max Power Dissipation 4W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature OCP, OTP, SCP, UVLO
Size / Dimension 0.12Lx0.10W x 0.06 H 3.0mmx2.6mmx1.5mm
Series SIMPLE SWITCHER? Nano
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-LDFN Exposed Pad, Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 12 Weeks
