DCV010505DP-U/700
RoHS
RoHS compliant
RoHS compliantPackage 14-SMD Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
IC REG ISO FIX/ADJ 0.1A DL 7SOP
PDF
/
Inventory: 6796
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SMD Module, 7 Leads
Number of Pins 7
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series DCV01 (1W)
Size / Dimension 0.78Lx0.33W x 0.21 H 19.7mmx8.3mmx5.3mm
Feature OTP, SCP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology BCDMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DCV010505
Pin Count 14
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 80%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 5.5V
Output Voltage -5V
Max Output Current 100mA
Voltage - Output 1 5V
Operating Supply Voltage 5.5V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Current - Output (Max) 100mA 100mA
Output Current 100mA
Control Features Enable, Active High
Total Power Output-Max 1W
Switching Frequency 400kHz
Dimensions
Height 5.334mm
Length 19.18mm
Width 6.604mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
