DCR012403P

Texas Instruments
RoHS
/
Package PDIP
Category Power Supplies - Board Mount / DC DC Converters
Description
PDF
/
Buying Options
Total Price: USD $23.54
Unit Price: USD $23.541053
≥1 USD $23.541053
≥100 USD $20.189665
≥250 USD $15.422918
≥1000 USD $13.601211
Inventory: 3530
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Package / Case PDIP
Surface Mount NO
Number of Pins 10

Technical

JESD-609 Code e4
Feature OTP, SCP
Pbfree Code yes
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Other Analog ICs
Power Rating 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Number of Functions 1
Terminal Pitch 2.54mm
Number of Outputs 1
Approval Agency UL
Voltage - Isolation 1kV
Output Voltage 3.3V
Output Type Fixed
Max Output Current 390mA
Voltage - Output 1 3.3V
Input Voltage-Nom 24V
Temperature Grade INDUSTRIAL
Trim/Adjustable Output NO
Analog IC - Other Type DC-DC REGULATED POWER SUPPLY MODULE
Power Dissipation-Max 1W
Current - Output 300mA
Quiescent Current 17mA
Max Output Voltage 3.366V
Voltage - Output 3.234V
Protections THERMAL
Min Input Voltage 21.6V
Control Mode VOLTAGE
Frequency - Switching 880kHz
Max Input Voltage 26.4V
Current - Output 1 300mA
Min Output Voltage 3.234V
Max Output Power 1W
Power - Output 1W
Load Regulation-Max(%) 2.5%
Ripple Voltage (Main Out) 0.003Vrms

Dimensions

Height 4.95mm
Length 22.86mm
Width 6.61mm
Thickness 3.94mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
