DCPA10505DP
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V
PDF
/
Buying Options
Total Price: USD $10.76
Unit Price: USD $10.756993
≥1 USD $10.756993
≥100 USD $8.609847
≥250 USD $6.704735
≥1000 USD $5.60703
Inventory: 1696
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 3.94mm
Width 6.61mm
Length 19.18mm
Height 5.33mm
Technical
Total Power Output-Max 1W
Control Mode VOLTAGE
Voltage - Output 2 -5V
Protections THERMAL
Current - Output (Max) 100mA 100mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 5.5V
Voltage - Isolation 2kV
Efficiency 85%
Approval Agency UL
Number of Outputs 2
Base Part Number DCPA10505
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Power (Watts) 1W
Applications ITE (Commercial)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 0.76Lx0.26W x 0.21 H 19.2mmx6.6mmx5.3mm
Series DCPA1 (1W)
Operating Temperature -40°C~100°C
Physical
Number of Pins 7
Surface Mount NO
Package / Case 14-DIP (0.300, 7.62mm), 7 Leads
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
