DCP022412DP
RoHS
/
Package 14-DIP (0.300, 7.62mm), 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
IC REG ISOLATED +/-1.2V DL 7DIP
PDF
/
Inventory: 7544
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 7 Leads
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series DCP02 (2W)
Size / Dimension 0.78Lx0.33W x 0.21 H 19.7mmx8.3mmx5.3mm
Feature OTP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 2W
Subcategory Other Analog ICs
Max Power Dissipation 456mW
Technology HYBRID
Terminal Position DUAL
Number of Functions 1
Base Part Number DCP022412
Pin Count 14/7
JESD-30 Code R-PDIP-T7
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 83%
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 12V
Max Output Current 83mA
Voltage - Output 1 12V
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 83mA 83mA
Voltage - Output 2 -12V
Total Power Output-Max 2W
Dimensions
Height 5.334mm
Length 19.18mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
