DCP021515U/1K
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width), 12 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 15V 2W
PDF
/
Buying Options
Total Price: USD $24.16
Unit Price: USD $24.16325
≥1 USD $24.16325
≥10 USD $19.8265
≥100 USD $19.2071
≥500 USD $18.5877
≥1000 USD $17.96735
Inventory: 477
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.3mm
Width 7.5mm
Height 2.65mm
Technical
Switching Frequency 400kHz
Max Output Power 2W
Min Output Voltage 14.25V
Current - Output 1 133mA
Control Mode VOLTAGE
Max Output Voltage 15.75V
Output Power 2W
Quiescent Current 15mA
Output Current 133mA
Trim/Adjustable Output NO
Input Voltage-Nom 15V
Voltage - Input (Min) 13.5V
Voltage - Output 1 15V
Max Output Current 133mA
Output Type Fixed
Output Voltage 15.75V
Voltage - Input (Max) 16.5V
Voltage - Isolation 1kV
Efficiency 88%
Approval Agency UL
Number of Outputs 1
Base Part Number DCP021515
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 180mW
Power Rating 2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature OTP
JESD-609 Code e4
Size / Dimension 0.71Lx0.30W x 0.10 H 18.1mmx7.6mmx2.7mm
Series DCP02 (2W)
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 12
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width), 12 Leads
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 8 Weeks
