DCP021205U
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width), 12 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
IC, 2W DC/DC CONV 12V/5V 28-SOIC
PDF
/
Buying Options
Total Price: USD $14.26
Unit Price: USD $14.256
≥1 USD $14.256
≥10 USD $14.14688
≥100 USD $14.03864
≥500 USD $13.8226
≥1000 USD $13.390617
≥3000 USD $12.094817
Inventory: 286
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width), 12 Leads
Surface Mount YES
Number of Pins 12
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series DCP02 (2W)
Size / Dimension 0.71Lx0.30W x 0.10 H 18.1mmx7.6mmx2.7mm
JESD-609 Code e4
Feature OTP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
Termination SMD/SMT
ECCN Code EAR99
Type Isolated Module
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 2W
Max Power Dissipation 70mW
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Frequency 800kHz
Base Part Number DCP021205
Number of Outputs 1
Efficiency 83%
Voltage - Isolation 1kV
Output Voltage 5V
Output Type Fixed
Max Output Current 400mA
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Max Supply Voltage 13.2V
Min Supply Voltage 10.8V
Output Current 400mA
Quiescent Current 14mA
Output Power 2W
Max Output Voltage 5.25V
Control Mode VOLTAGE
Current - Output 1 400mA
Min Output Voltage 4.75V
Max Output Power 2W
Nominal Output Voltage 5V
Switching Frequency 400kHz
Ripple Voltage (Main Out) 0.007Vrms
Dimensions
Height 2.65mm
Width 7.5mm
Thickness 2.3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
