78SR112HC image
Favorite
78SR112HC image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description TEXAS INSTRUMENTS 78SR112HC Linear Regulator DC/DC Converter, Fixed, Through Hole, 1 Output, 12 V, 1.5 A
PDF
/
Buying Options
Total Price: USD $37.06
Unit Price: USD $37.058053
≥1 USD $37.058053
≥10 USD $34.960432
≥100 USD $32.981541
≥500 USD $31.114652
≥1000 USD $29.353455
Inventory: 5793
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Height 7.874mm

Technical

Min Input Voltage (DC) 14.5V
Max Input Voltage (DC) 30V
Nominal Output Voltage 12V
Switcher Configuration BUCK
Current - Output 1 1.5A
Control Mode VOLTAGE-MODE
Output Power 18W
Output Current 400mA
Input Voltage-Nom 16V
Max Output Current 1.5A
Output Voltage 12V
Efficiency 90%
Number of Outputs 1
Pin Count 3
Base Part Number 78SR112
Frequency 650kHz
Current Rating 400mA
Depth 22.86mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 18W
Subcategory Switching Regulator or Controllers
HTS Code 8504.40.85.00
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature OTP, SCP
Size / Dimension 0.94Lx0.90W x 0.31 H 23.9mmx22.9mmx7.9mm
Series 78SR100
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Weight 6.5g
Number of Pins 3
Package / Case 3-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Tin
