78HT205HC image
Favorite
78HT205HC image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR 5V/2A 28VIN INT SW HRZ
PDF
/
Inventory: 1520
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 7.874mm

Technical

Switching Frequency-Max 800kHz
Switcher Configuration BUCK
Output Current 2A
Input Voltage-Nom 9V
Voltage - Input (Min) 7V
Max Output Current 2A
Output Voltage 5V
Voltage - Input (Max) 28V
Efficiency 82%
Number of Outputs 1
Pin Count 3
Base Part Number 78HT205
Current Rating 2A
Depth 22.86mm
Number of Functions 1
Terminal Position SINGLE
Max Power Dissipation 10W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature OTP, SCP
Size / Dimension 0.94Lx0.90W x 0.31 H 23.9mmx22.9mmx7.9mm
Series 78HT200
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Weight 7g
Number of Pins 3
Package / Case 3-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Tin
