PXE3048D12
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONVRT +/-12V 30W +/-1.
PDF
/
Buying Options
Total Price: USD $92.5
Unit Price: USD $92.500848
≥1 USD $92.500848
≥10 USD $87.264947
≥100 USD $82.325426
≥500 USD $77.665496
≥1000 USD $73.269334
Inventory: 2689
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 40.6mm
Length 50.8mm
Height 10.16mm
Technical
Current - Output 1 1.25A
Voltage - Output 2 -12V
Output Power 30W
Current - Output (Max) 1.25A 1.25A
Voltage - Input (Min) 36V
Voltage - Output 1 12V
Max Output Current 1.25A
Output Voltage 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.6kV
Efficiency 88%
Approval Agency CE, CSA, EN, UL
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 30W
Subcategory Power Supply Modules
Additional Feature REMOTE SHUTDOWN
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 2.00Lx1.60W x 0.40 H 50.8mmx40.6mmx8.6mm
Series PXE (30W)
Published 2005
Packaging Bulk
Operating Temperature -40°C~100°C
Physical
Number of Pins 7
Package / Case 8-DIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
