PXD2012D12
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONVTR +/-12V 20W +/-.833A
PDF
/
Inventory: 905
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 50.8mm
Height 10.16mm
Technical
Current - Output 1 833mA
Voltage - Output 2 -12V
Output Power 20W
Current - Output (Max) 833mA 833mA
Trim/Adjustable Output NO
Temperature Grade OTHER
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Voltage - Output 1 12V
Max Output Current 833mA
Output Voltage 12V
Voltage - Input (Max) 18V
Voltage - Isolation 1.6kV
Efficiency 86%
Operating Temperature (Min) -40°C
Operating Temperature (Max) 71°C
Approval Agency UL
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 20W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Series PXD (20W)
Physical
Number of Pins 6
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
