PXCM0324WS3P3A
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER 3.3V 1A PCB
PDF
/
Buying Options
Total Price: USD $43.91
Unit Price: USD $43.910106
≥1 USD $43.910106
≥10 USD $41.424626
≥100 USD $39.079842
≥500 USD $36.86777
≥1000 USD $34.780916
Inventory: 1084
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 5 Leads
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Published 2015
Series PXC-M03 (3W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications Medical
Power (Watts) 3W
Max Power Dissipation 3W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XXMA-X7
Number of Outputs 1
Efficiency 82%
Voltage - Isolation 5kV
Voltage - Input (Max) 36V
Output Voltage 3.3V
Max Output Current 1A
Voltage - Output 1 3.3V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Output Power 3.3W
Total Power Output-Max 3W
Dimensions
Height 10.16mm
Width 20.3mm
Compliance
RoHS Status RoHS Compliant
