PXCM0324WS12A
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER 12V .25A PCB
PDF
/
Buying Options
Total Price: USD $47.6
Unit Price: USD $47.601658
≥1 USD $47.601658
≥10 USD $44.907225
≥100 USD $42.36531
≥500 USD $39.967276
≥1000 USD $37.704972
Inventory: 1464
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 20.3mm
Height 10.16mm
Technical
Total Power Output-Max 3W
Output Power 3W
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Voltage - Output 1 12V
Max Output Current 250mA
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 5kV
Efficiency 87%
Number of Outputs 1
JESD-30 Code R-XXMA-X7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 3W
Applications Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series PXC-M03 (3W)
Published 2015
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Package / Case 24-DIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
