PSD651212
RoHS
/
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V
PDF
/
Inventory: 6751
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 7.874mm
Technical
Isolation Isolated
Total Power Output-Max 6W
Current - Output 1 250mA
Voltage - Output 2 -12V
Output Power 6W
Output Current 250mA
Current - Output (Max) 250mA 250mA
Trim/Adjustable Output YES
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 9V
Efficiency 84%
Number of Outputs 2
JESD-30 Code R-XDMA-T7
Depth 20.5mm
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Power Rating 6W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Remote On/Off, OCP
Size / Dimension 1.12Lx0.80W x 0.31 H 28.4mmx20.3mmx8.0mm
Series PSD (6W)
Published 2006
Operating Temperature -40°C~85°C With Derating
Physical
Number of Pins 11
Surface Mount NO
Package / Case 6-DIP Module
Mounting Type Through Hole
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 month ago)
