PSD3481212
RoHS
/
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 3W 12V 0.125A
PDF
/
Inventory: 8046
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
Physical
Mounting Type Through Hole
Package / Case 6-DIP Module
Surface Mount NO
Number of Pins 11
Technical
Operating Temperature -40°C~85°C With Derating
Published 2005
Series PSD (3W)
Size / Dimension 1.02Lx0.63W x 0.31 H 25.9mmx16.0mmx8.0mm
Feature Remote On/Off, OCP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power Rating 3W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 16mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-T7
Number of Outputs 2
Efficiency 84%
Voltage - Input (Max) 76V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Current - Output (Max) 130mA 130mA
Output Current 125mA
Output Power 3W
Voltage - Output 2 -12V
Current - Output 1 125mA
Total Power Output-Max 3W
Isolation Isolated
Dimensions
Height 7.874mm
Compliance
RoHS Status RoHS Compliant
