PSD1051212/S
RoHS
/
Package 6-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V
PDF
/
Inventory: 6857
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 6-SMD Module
Technical
Operating Temperature -40°C~85°C With Derating
Published 2006
Series PSD (10W)
Size / Dimension 1.59Lx0.87W x 0.31 H 40.4mmx22.1mmx8.0mm
Feature Remote On/Off, OCP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 8W
Number of Outputs 2
Efficiency 84%
Voltage - Input (Max) 9V
Voltage - Output 1 12V
Voltage - Input (Min) 4.5V
Current - Output (Max) 350mA 350mA
Voltage - Output 2 -12V
