PH600S280-12
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 600W 12V 50A
PDF
/
Inventory: 10005
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Module
Surface Mount NO
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2006
Series PH-S (600W)
Size / Dimension 3.85Lx1.61W x 0.50 H 86.0mmx41.0mmx12.7mm
Feature Remote On/Off, OCP, OTP, OVP
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 600W
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XXFM-X
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Isolation 3kV
Voltage - Input (Max) 400V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 200V
Input Voltage-Nom 280V
Trim/Adjustable Output YES
Current - Output (Max) 50A
Control Features Enable, Active Low
Total Power Output-Max 600W
Compliance
RoHS Status RoHS Compliant
