PAH200H483R3/V

TDK-Lambda Americas Inc.
RoHS
/
Package 14-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description Isolated DC/DC Converters 198W 3.3V 60A
PDF
/
Inventory: 1396
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 57.9mm
Height 12.7mm

Technical

Current - Output 1 60A
Control Features Enable, Active Low
Output Power 198W
Output Current 60A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 60A
Output Voltage 3.3V
Voltage - Input (Max) 76V
Voltage - Isolation 1.5kV
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 198W
Power Rating 198W
Subcategory Other Analog ICs
Power (Watts) 200W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, OCP, OVP
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Series PAH200H (200W)
Published 2004
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Number of Pins 10
Package / Case 14-DIP Module
Mounting Type Through Hole
Mount Through Hole
