CC30-4815SFP-E
RoHS
/
Package 20-DIP Module, 17 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 30W 48V 15V 2A PCB
PDF
/
Inventory: 7317
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Length 38.4mm
Height 8.382mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 76V
Nominal Output Voltage 15V
Max Output Power 30W
Nominal Input Voltage 48V
Current - Output 1 2A
Control Features Enable, Active Low
Output Power 30W
Output Current 2A
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Max Output Current 2A
Output Voltage 15V
Voltage - Input (Max) 76V
Voltage - Isolation 1kV
Efficiency 89%
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 33.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 30W
Power Rating 30W
Applications ITE (Commercial)
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Type Isolated Module
ECCN Code EAR99
Number of Terminations 17
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 1.51Lx1.32W x 0.33 H 38.4mmx33.5mmx8.3mm
Series CC-P-E (30W)
Published 2009
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 20-DIP Module, 17 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
