CC15-4815SFP-E
RoHS
/
Package 20-DIP Module, 17 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 15W 48V 15V 1A PCB
PDF
/
Buying Options
Total Price: USD $46.2
Unit Price: USD $46.200161
≥1 USD $46.200161
≥10 USD $43.585053
≥100 USD $41.117975
≥500 USD $38.790538
≥1000 USD $36.594854
Inventory: 1163
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Length 38.4mm
Height 6.858mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 76V
Nominal Output Voltage 15V
Max Output Power 15W
Nominal Input Voltage 48V
Current - Output 1 1A
Control Features Enable, Active Low
Output Power 15W
Output Current 1A
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Max Output Current 1A
Output Voltage 15V
Voltage - Input (Max) 76V
Voltage - Isolation 1kV
Efficiency 89%
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 29.6mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Power Rating 15W
Applications ITE (Commercial)
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Type Isolated Module
ECCN Code EAR99
Number of Terminations 17
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 1.51Lx1.17W x 0.27 H 38.4mmx29.6mmx6.8mm
Series CC-P-E (15W)
Published 2009
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 17
Package / Case 20-DIP Module, 17 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
Factory Lead Time 14 Weeks
