RY-1209S
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 12VIN 09VOUT
PDF
/
Buying Options
Total Price: USD $9.44
Unit Price: USD $9.4424
≥1 USD $9.4424
≥10 USD $9.35792
≥100 USD $9.28664
≥500 USD $9.143904
≥1000 USD $8.858256
≥3000 USD $8.096
Inventory: 93
Minimum: 1
-
+
Technical Details
Technical
Nominal Input Voltage 12V
Total Power Output-Max 1W
Max Output Voltage 9V
Output Power 1W
Output Current 111mA
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Voltage - Input (Min) 11.4V
Voltage - Output 1 9V
Max Output Current 111mA
Output Voltage 1V
Voltage - Input (Max) 12.6V
Voltage - Isolation 1kV
Efficiency 62%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-P5
Pin Count 7/5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.28W x 0.40 H 19.7mmx7.1mmx10.2mm
Series ECONOLINE RY (1W)
Packaging Tube
Operating Temperature -40°C~70°C
Dimensions
Height 10.2mm
Width 7.05mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 2.8g
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
