RW2-4815S/H2
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 36-72VIN 15VOUT
PDF
/
Inventory: 1746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP Module, 6 Leads
Weight 6.4g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RW2 (2W)
Size / Dimension 0.95Lx0.57W x 0.38 H 24.2mmx14.5mmx9.7mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Max Power Dissipation 2W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-T6
Number of Outputs 1
Efficiency 81%
Voltage - Isolation 2kV
Voltage - Input (Max) 72V
Output Voltage 15V
Max Output Current 134mA
Voltage - Input (Min) 36V
Trim/Adjustable Output NO
Output Current 134mA
Output Power 2W
Max Output Voltage 15V
Total Power Output-Max 2W
Nominal Input Voltage 48V
Dimensions
Height 14.5mm
Length 24.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
