RW2-2415D/H3/SMD
RoHS
RoHS compliant
RoHS compliantPackage 16-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 18-36VIN +/-15VOUT
PDF
/
Buying Options
Total Price: USD $20.46
Unit Price: USD $20.457024
≥1 USD $20.457024
≥10 USD $19.299082
≥100 USD $18.206679
≥500 USD $17.17612
≥1000 USD $16.203877
Inventory: 8827
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SMD Module, 6 Leads
Number of Pins 6
Weight 6.4g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RW2 (2W)
Size / Dimension 0.95Lx0.57W x 0.40 H 24.2mmx14.5mmx10.2mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Max Power Dissipation 2W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 14.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
Number of Outputs 2
Efficiency 83%
Voltage - Isolation 3kV
Voltage - Input (Max) 36V
Output Voltage 15V
Max Output Current 67mA
Voltage - Input (Min) 18V
Trim/Adjustable Output NO
Current - Output (Max) 67mA 67mA
Output Current 67mA
Output Power 2W
Max Output Voltage 15V
Voltage - Output 2 -15V
Total Power Output-Max 1W
Nominal Input Voltage 24V
Isolation Isolated
Dimensions
Height 10.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
