RW2-1212D/H3
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 9-18VIN +/-12VOUT
PDF
/
Inventory: 8687
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 14.5mm
Technical
Nominal Input Voltage 12V
Total Power Output-Max 1W
Voltage - Output 2 -12V
Max Output Voltage 12V
Output Power 2W
Output Current 83mA
Current - Output (Max) 83mA 83mA
Trim/Adjustable Output NO
Voltage - Input (Min) 9V
Max Output Current 83mA
Output Voltage 12V
Voltage - Input (Max) 18V
Voltage - Isolation 3kV
Efficiency 80%
Number of Outputs 2
JESD-30 Code R-XDMA-T6
Pin Count 16/6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 2W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.95Lx0.57W x 0.38 H 24.2mmx14.5mmx9.7mm
Series ECONOLINE RW2 (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 6.4g
Package / Case 16-DIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
