RV-3.309D
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 14 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 3.3VIN +/-09VOUT
PDF
/
Inventory: 2884
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 11.4mm
Technical
Nominal Input Voltage 3.3V
Total Power Output-Max 2W
Voltage - Output 2 -9V
Max Output Voltage 9V
Output Power 2W
Output Current 111mA
Current - Output (Max) 111mA 111mA
Trim/Adjustable Output NO
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3V
Max Output Current 111mA
Output Voltage 9V
Voltage - Input (Max) 3.6V
Voltage - Isolation 6kV
Efficiency 75%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XDMA-T14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 1.27Lx0.58W x 0.45 H 32.4mmx14.7mmx11.4mm
Series ECONOLINE RV (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 9g
Package / Case 24-DIP Module, 14 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
