RV-1209S
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 14 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 12VIN 09VOUT
PDF
/
Buying Options
Total Price: USD $14.28
Unit Price: USD $14.279234
≥1 USD $14.279234
≥10 USD $13.470977
≥100 USD $12.708467
≥500 USD $11.98912
≥1000 USD $11.310495
Inventory: 1128
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 32.35mm
Height 11.4mm
Technical
Nominal Input Voltage 12V
Total Power Output-Max 2W
Max Output Voltage 9V
Output Power 2W
Output Current 222mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 222mA
Output Voltage 9V
Voltage - Input (Max) 13.2V
Voltage - Isolation 6kV
Efficiency 75%
Qualification Status Not Qualified
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 2W
Subcategory Other Analog ICs
Additional Feature SEATED HGT CALCULATED
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 1.27Lx0.58W x 0.45 H 32.4mmx14.7mmx11.4mm
Series ECONOLINE RV (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 9g
Package / Case 24-DIP Module, 14 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
