RTS-2412
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 24VIN 12VOUT
PDF
/
Inventory: 2122
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 8.89mm
Technical
Isolation Isolated
Nominal Input Voltage 24V
Output Power 2W
Output Current 167mA
Voltage - Input (Min) 21.6V
Voltage - Output 1 12V
Max Output Current 167mA
Output Voltage 12V
Voltage - Input (Max) 26.4V
Voltage - Isolation 1kV
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
Depth 9.3mm
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature SCP
Size / Dimension 0.50Lx0.37W x 0.35 H 12.8mmx9.3mmx9.0mm
Series ECONOLINE RTS (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Package / Case 8-SMD Module, 5 Leads
Mounting Type Surface Mount
Mount Surface Mount
