RSZ-053.3/HP
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 1W
PDF
/
Inventory: 7533
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module, 6 Leads
Number of Pins 6
Technical
Operating Temperature -40°C~70°C
Packaging Tube
Series ECONOLINE RSZ (1W)
Size / Dimension 0.60Lx0.37W x 0.35 H 15.2mmx9.3mmx9.0mm
Feature SCP
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 660mW
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 9.3mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 1
Efficiency 60%
Voltage - Isolation 2kV
Voltage - Input (Max) 5.5V
Output Voltage 3.3V
Max Output Current 200mA
Voltage - Output 1 3.3V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Output Current 200mA
Output Power 1W
Total Power Output-Max 1W
Nominal Input Voltage 5V
Isolation Isolated
Dimensions
Height 8.89mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
