RSZ-0505/H
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 05VIN 05VOUT
PDF
/
Inventory: 4203
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 8.89mm
Technical
Isolation Isolated
Nominal Input Voltage 5V
Output Power 1W
Output Current 200mA
Voltage - Input (Min) 4.5V
Max Output Current 200mA
Output Voltage 5V
Voltage - Input (Max) 5.5V
Voltage - Isolation 2kV
Efficiency 60%
Number of Outputs 1
Reach Compliance Code unknown
Depth 9.3mm
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature SCP
Size / Dimension 0.60Lx0.37W x 0.35 H 15.2mmx9.3mmx9.0mm
Series ECONOLINE RSZ (1W)
Packaging Tube
Operating Temperature -40°C~70°C
Physical
Number of Pins 6
Package / Case 10-SMD Module, 6 Leads
Mounting Type Surface Mount
Mount Surface Mount
