RSS-3.315-R
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 3.3VIN 15VOUT
PDF
/
Inventory: 2703
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.9mm
Height Seated (Max) 7.55mm
Technical
Total Power Output-Max 1W
Current - Output (Max) 66mA
Trim/Adjustable Output NO
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 3.6V
Voltage - Isolation 1kV
Efficiency 82%
Number of Outputs 1
JESD-30 Code R-XDMA-G5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power (Watts) 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature SCP
Size / Dimension 0.50Lx0.32W x 0.29 H 12.8mmx8.2mmx7.3mm
Series ECONOLINE RSS (1W)
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-SMD Module, 5 Leads
Mounting Type Surface Mount
