RSS-243.3/H-R
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 24VIN 3.3VOUT
PDF
/
Inventory: 8678
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.9mm
Height Seated (Max) 7.55mm
Technical
Total Power Output-Max 1W
Current - Output (Max) 303mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 21.6V
Voltage - Output 1 3.3V
Output Voltage 3.3V
Voltage - Input (Max) 26.4V
Voltage - Isolation 3kV
Efficiency 75%
Number of Outputs 1
JESD-30 Code R-XDMA-G5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power (Watts) 1W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature SCP
Size / Dimension 0.50Lx0.32W x 0.29 H 12.8mmx8.2mmx7.3mm
Series ECONOLINE RSS (1W)
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-SMD Module, 5 Leads
Mounting Type Surface Mount
