RSS-1512/P
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 15VIN 12VOUT
PDF
/
Inventory: 6835
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SMD Module, 5 Leads
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RSS (1W)
Size / Dimension 0.50Lx0.32W x 0.29 H 12.8mmx8.2mmx7.3mm
Feature SCP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Total Power Output-Max 1W
Current - Output (Max) 84mA
Trim/Adjustable Output NO
Input Voltage-Nom 15V
Voltage - Input (Min) 13.5V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 16.5V
Voltage - Isolation 1kV
Efficiency 80%
Number of Outputs 1
JESD-30 Code R-XDMA-G5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power (Watts) 1W
Applications ITE (Commercial)
Type Isolated Module
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.9mm
Height Seated (Max) 7.55mm
