RSS-1215
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 12VIN 15VOUT
PDF
/
Inventory: 1626
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.9mm
Height 7.366mm
Technical
Isolation Isolated
Nominal Input Voltage 12V
Total Power Output-Max 1W
Output Power 1W
Output Current 66mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Voltage - Output 1 15V
Max Output Current 66mA
Output Voltage 15V
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 82%
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Depth 8.15mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature SCP
Size / Dimension 0.50Lx0.32W x 0.29 H 12.8mmx8.2mmx7.3mm
Series ECONOLINE RSS (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Package / Case 8-SMD Module, 5 Leads
Mounting Type Surface Mount
Mount Surface Mount
