RSO-1205S/H2
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 9-18VIN 05VOUT
PDF
/
Buying Options
Total Price: USD $20.2
Unit Price: USD $20.19963
≥1 USD $20.19963
≥10 USD $19.05626
≥100 USD $17.9776
≥500 USD $16.96
≥1000 USD $16
≥3000 USD $15.09434
Inventory: 1188
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Weight 4.7g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RSO (1W)
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Feature Remote On/Off, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8/7
JESD-30 Code R-XSMA-T7
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 2kV
Voltage - Input (Max) 18V
Output Voltage 5V
Max Output Current 200mA
Voltage - Input (Min) 9V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 200mA
Output Power 1W
Control Features Enable, Active Low
Max Output Voltage 5V
Total Power Output-Max 1W
Nominal Input Voltage 12V
Dimensions
Height 11.1mm
Width 9.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
