RS3-2412DZ/H2
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 3W
PDF
/
Buying Options
Total Price: USD $22.02
Unit Price: USD $22.018164
≥1 USD $22.018164
≥10 USD $20.771849
≥100 USD $19.596087
≥500 USD $18.486871
≥1000 USD $17.440444
Inventory: 4397
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 11.1mm
Technical
Nominal Input Voltage 24V
Total Power Output-Max 3W
Voltage - Output 2 -12V
Max Output Voltage 12V
Control Features Enable, Active Low
Output Power 3W
Output Current 125mA
Current - Output (Max) 125mA 125mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Max Output Current 125mA
Output Voltage 12V
Voltage - Input (Max) 27V
Voltage - Isolation 2kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XSMA-T7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 3W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Series ECONOLINE RS3 (3W)
Packaging Tube
Operating Temperature -40°C~71°C
Physical
Weight 4.7g
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
