RS12-2412SZ
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
12W DC/DC-CONVERTER 'ECONOLINE'
PDF
/
Buying Options
Total Price: USD $28.7
Unit Price: USD $28.6968
≥1 USD $28.6968
≥10 USD $28.03328
≥100 USD $27.81592
≥500 USD $27.381376
≥1000 USD $26.077392
≥3000 USD $24.596088
Inventory: 467
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Technical
Operating Temperature -40°C~75°C
Series ECONOLINE RS12-Z (12W)
Size / Dimension 0.86Lx0.38W x 0.49 H 21.8mmx9.6mmx12.6mm
Feature Remote On/Off
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 12W
Number of Outputs 1
Efficiency 88%
Voltage - Isolation 3kV
Voltage - Input (Max) 36V
Voltage - Output 1 12V
Voltage - Input (Min) 9V
Current - Output (Max) 1A
Control Features Enable, Active Floating
Compliance
RoHS Status ROHS3 Compliant
