RS-053.3D
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 4.5-9VIN +/-3.3V
PDF
/
Inventory: 1616
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 9.2mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8/7
Number of Outputs 2
Efficiency 69%
Voltage - Isolation 1kV
Voltage - Input (Max) 9V
Output Voltage 3.3V
Max Output Current 250mA
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Current - Output (Max) 250mA 250mA
Output Current 250mA
Output Power 2W
Control Features Enable, Active Low
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Series ECONOLINE RS (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Isolation Isolated
Nominal Input Voltage 5V
Total Power Output-Max 1.65W
Voltage - Output 2 -3.3V
Max Output Voltage 3.3V
Physical
Weight 4.7g
Number of Pins 7
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 11.1mm
