RS-0505S/H2
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
2W DC/DC-Converter 'ECONOLINE' SIP8 2kV reg 2: 1; V. In: 4.5-9; V. Out: 05; mA. Out: 400
PDF
/
Buying Options
Total Price: USD $17.7
Unit Price: USD $17.6968
≥1 USD $17.6968
≥10 USD $17.28496
≥100 USD $17.15032
≥500 USD $16.882272
≥1000 USD $16.078304
≥3000 USD $15.1712
Inventory: 1107
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 11.1mm
Technical
Isolation Isolated
Nominal Input Voltage 5V
Total Power Output-Max 2W
Max Output Voltage 5V
Control Features Enable, Active Low
Output Power 2W
Output Current 400mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 400mA
Output Voltage 5V
Voltage - Input (Max) 9V
Voltage - Isolation 2kV
Efficiency 75%
Number of Outputs 1
Pin Count 8/7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 9.2mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 2W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Series ECONOLINE RS (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 4.7g
Number of Pins 7
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
