RS-0505D
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W DL +/-5V OUT SIP8
PDF
/
Buying Options
Total Price: USD $20.2
Unit Price: USD $20.19963
≥1 USD $20.19963
≥10 USD $19.05626
≥100 USD $17.9776
≥500 USD $16.96
≥1000 USD $16
≥3000 USD $15.09434
Inventory: 1600
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 11.1mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 9V
Current - Output 2 200mA
Isolation Isolated
Max Output Power 2W
Nominal Input Voltage 5V
Current - Output 1 200mA
Voltage - Output 2 -5V
Max Output Voltage 5V
Control Features Enable, Active Low
Output Power 2W
Output Current 200mA
Current - Output (Max) 200mA 200mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Max Output Current 200mA
Output Voltage 5V
Voltage - Isolation 1kV
Efficiency 75%
Number of Outputs 2
Pin Count 8/7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 9.2mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 2W
Power Rating 2W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Series ECONOLINE RS (2W)
Packaging Tube
Operating Temperature -45°C~85°C
Physical
Weight 4.7g
Number of Pins 7
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 9 Weeks
