RPP40-2405SW
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
40W DC/DC-CONV POWERLINE-PLUS
PDF
/
Inventory: 1354
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Number of Pins 5
Weight 39g
Technical
Operating Temperature -45°C~66°C
Packaging Tube
Series POWERLINE+ RPP40-W (40W)
Size / Dimension 2.00Lx1.20W x 0.46 H 50.8mmx30.5mmx11.7mm
Feature Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 40W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 30.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 6
JESD-30 Code R-MDMA-P6
Number of Outputs 1
Efficiency 88%
Voltage - Isolation 3kV
Voltage - Input (Max) 36V
Output Voltage 4.5V
Max Output Current 8A
Voltage - Output 1 5V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Output Current 8A
Output Power 40W
Control Features Enable, Active High
Max Output Voltage 5.5V
Isolation Isolated
Dimensions
Height 12.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
