RP60-483.3SG
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 60W 36-75VIN 3.3VOUT
PDF
/
Inventory: 4128
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP Module
Number of Pins 8
Weight 60g
Technical
Operating Temperature -40°C~40°C
Packaging Tube
Series POWERLINE RP60-G (60W)
Size / Dimension 2.00Lx2.00W x 0.40 H 50.8mmx50.8mmx10.2mm
Feature Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature SEATED HGT-NOM
Subcategory Other Analog ICs
Max Power Dissipation 46.2W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 50.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 89%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 75V
Output Voltage 3.3V
Max Output Current 14A
Voltage - Output 1 3.3V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Output Current 14A
Output Power 60W
Control Features Enable, Active High
Max Output Voltage 3.63V
Nominal Input Voltage 48V
Dimensions
Height 10.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
