RP20-4812SA
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC-CONVERTER 850UF 20 WATTS OUTPUT POWER
PDF
/
Inventory: 4912
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-SIP Module, 4 Leads
Weight 15g
Technical
Operating Temperature -40°C~90°C
Packaging Tube
Series POWERLINE RP20-A (20W)
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Feature OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Type Isolated Module
Applications ITE (Commercial)
Capacitance 850μF
Max Power Dissipation 20W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code S-XDMA-P4
Number of Outputs 1
Efficiency 90%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 75V
Output Voltage 12V
Max Output Current 1.67A
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Current 1.67A
Output Power 20W
Max Output Voltage 12V
Dimensions
Height 9.9mm
Length 25.4mm
Width 25.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
