RP15-243.3SOF/P
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 15W 18-36VIN 3.3VOUT
PDF
/
Inventory: 2707
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 27.9mm
Height 8.5mm
Technical
Isolation Isolated
Nominal Input Voltage 24V
Max Output Voltage 3.63V
Control Features Enable, Active High
Output Power 15W
Output Current 3.5A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 3.3V
Max Output Current 3.5A
Output Voltage 3.3V
Voltage - Input (Max) 36V
Voltage - Isolation 2.25kV
Efficiency 86%
Number of Outputs 1
Depth 23.9mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 12W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 1.10Lx0.94W x 0.33 H 27.9mmx23.9mmx8.5mm
Series POWERLINE RP15-SOF (15W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 10.5g
Number of Pins 6
Package / Case 6-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
