RP15-2412SAW

Recom Power
RoHS
RoHS RoHS compliant
Package 6-DIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 15W SGL 12VOUT
PDF
/
Buying Options
Total Price: USD $78.27
Unit Price: USD $78.27357
≥1 USD $78.27357
≥10 USD $73.84299
≥100 USD $69.6632
≥500 USD $65.72
≥1000 USD $62
≥3000 USD $58.49057
Inventory: 1296
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module, 4 Leads
Number of Pins 4
Weight 15g

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Series POWERLINE RP15-AW (15W)
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Feature OCP, OVP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 15W
Max Power Dissipation 15W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Depth 25.4mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 87%
Voltage - Isolation 1.6kV
Output Voltage 12V
Max Output Current 1.3A
Output Current 1.3A
Output Power 15W
Max Output Voltage 12V
Current - Output 1 1.3A
Nominal Input Voltage 24V
Max Output Power 15W
Isolation Isolated
Nominal Output Voltage 12V
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 9V

Dimensions

Height 9.9mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
