RP15-1205DF/P
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 15W 9-18VIN +/-05VOUT
PDF
/
Buying Options
Total Price: USD $50.44
Unit Price: USD $50.441618
≥1 USD $50.441618
Inventory: 3700
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Number of Pins 6
Weight 27g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series POWERLINE RP15-F (15W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature Remote On/Off, OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 15W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 83%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 18V
Output Voltage 5V
Max Output Current 1.5A
Voltage - Input (Min) 9V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 1.5A 1.5A
Output Current 1.5A
Output Power 15W
Control Features Enable, Active High
Max Output Voltage 5V
Voltage - Output 2 -5V
Nominal Input Voltage 12V
Dimensions
Height 10.2mm
Length 50.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
