RP12-2405DAW/SMD
RoHS
RoHS compliant
RoHS compliantPackage 24-SMD Module, 18 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 12W 9-36VIN +/-05V
PDF
/
Inventory: 5080
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SMD Module, 18 Leads
Weight 20g
Technical
Operating Temperature -40°C~61°C
Packaging Tube
Series POWERLINE RP12-AW (12W)
Size / Dimension 1.26Lx0.80W x 0.44 H 32.0mmx20.3mmx11.2mm
Feature Remote On/Off, OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 12W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
JESD-30 Code R-PDMA-G18
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 84%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 36V
Output Voltage 5V
Max Output Current 1.2A
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 1.2A 1.2A
Output Current 1.2A
Output Power 12W
Control Features Enable, Active High
Max Output Voltage 5V
Voltage - Output 2 -5V
Nominal Input Voltage 24V
Dimensions
Height 11.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
